Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Coto Technology |
| Series | 9800 |
| Packaging | Tube |
| Part Status | Active |
| Coil Type | Non Latching |
| Coil Current | 33.3 mA |
| Coil Voltage | 5VDC |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 250 mA |
| Switching Voltage | 100VAC, 100VDC – Max |
| Must Operate Voltage | 3.8 VDC |
| Must Release Voltage | 0.4 VDC |
| Operate Time | 0.25 ms |
| Release Time | 0.05 ms |
| Features | Magnetic Shield |
| Mounting Type | Surface Mount |
| Termination Style | Gull Wing |
| Operating Temperature | -20°C ~ 85°C |
| Contact Material | – |
| Coil Power | – |
| Coil Resistance | 150 Ohms |
| Base Product Number | 9814 |
