Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Coto Technology |
| Series | 5500 |
| Packaging | Tube |
| Part Status | Active |
| Mounting Type | Through Hole |
| Coil Voltage | 12VDC |
| Contact Form | SPST-NC (1 Form B) |
| Contact Rating (Current) | 3 A |
| Switching Voltage | 7500VAC, 7500VDC – Max |
| Coil Current | 68.6 mA |
| Coil Type | Non Latching |
| Features | EMI Shielded |
| Termination Style | PC Pin |
| Seal Rating | – |
| Must Operate Voltage | 9 VDC |
| Must Release Voltage | 1 VDC |
| Operate Time | 3 ms |
| Release Time | 3 ms |
| Operating Temperature | -20°C ~ 85°C |
| Contact Material | – |
| Coil Resistance | 175 Ohms |
| Base Product Number | 5502 |
