Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Coto Technology |
| Series | 5000 |
| Packaging | Tube |
| Part Status | Active |
| Mounting Type | Through Hole |
| Coil Voltage | – |
| Contact Form | SPST-NO (1 Form A) |
| Contact Rating (Current) | 50 W |
| Switching Voltage | 5000VAC, 5000VDC – Max |
| Coil Type | Non Latching |
| Features | – |
| Termination Style | PC Pin |
| Seal Rating | – |
| Must Operate Voltage | 10 VDC |
| Must Release Voltage | 1.26 VDC |
| Operate Time | 3 ms |
| Release Time | 3 ms |
| Operating Temperature | -20°C ~ 85°C |
| Contact Material | – |
| Coil Resistance | 250 Ohms |
| Base Product Number | 5000 |
