Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Cornell Dubilier Knowles |
| Series | SF |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 30µF |
| Tolerance | ±10% |
| Voltage Rating – AC | 660V |
| Voltage Rating – DC | – |
| Dielectric Material | Polypropylene (PP), Metallized |
| Operating Temperature | -40°C ~ 70°C |
| Polarization | – |
| Applications | Motor Run |
| Lead Spacing | 0.810″ (20.57mm) |
| Size / Dimension | 3.660″ L x 1.970″ W (92.96mm x 50.04mm), Lip |
| Height – Seated (Max) | 4.030″ (102.36mm) |
| Mounting Type | Chassis Mount, Requires Holder/Bracket |
| Package / Case | Radial, Can |
