Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Cornell Dubilier Knowles |
| Series | CDV16 |
| Packaging | Bulk |
| Part Status | Active |
| Capacitance | 1000 pF |
| Tolerance | ±5% |
| Voltage – Rated | 1 kV |
| Dielectric Material | Mica |
| Operating Temperature | -55°C ~ 150°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Lead Spacing | 0.234″ (5.94mm) |
| Features | RF, High Q, Low Loss |
| Size / Dimension | 0.461″ L x 0.173″ W (11.70mm x 4.40mm) |
| Height – Seated (Max) | 0.500″ (12.70mm) |
