Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | C&K |
| Series | A |
| Packaging | Tray |
| Part Status | Active |
| Number of Positions | 6 |
| Index Stops | Fixed |
| Number of Decks | 1 |
| Number of Poles per Deck | 2 |
| Circuit per Deck | DP6T |
| Contact Timing | Non-Shorting (BBM) |
| Current Rating (Amps) | 0.4VA (AC/DC) |
| Voltage Rating – AC | 20 V |
| Voltage Rating – DC | 20 V |
| Actuator Type | Flatted (6.35mm Dia) |
| Actuator Length | 9.53mm |
| Angle of Throw | 30° |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Mounting Type | Panel Mount, Through Hole |
| Termination Style | PC Pin |
| Features | Modular Base |
| Depth Behind Panel | 14.48mm |
| Panel Cutout Dimensions | Circular – 10.21mm Dia |
| Base Product Number | A20603MN |
