Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Analog Devices Inc./Maxim Integrated |
| Series | – |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Switch Circuit | SPDT |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Number of Circuits | 1 |
| On-State Resistance (Max) | 60Ohm |
| Channel-to-Channel Matching (ΔRon) | 750mOhm |
| Voltage – Supply, Single (V+) | 1.8V ~ 12V |
| Voltage – Supply, Dual (V±) | ±1V ~ 6V |
| Switch Time (Ton, Toff) (Max) | 60ns, 40ns |
| -3db Bandwidth | 450MHz |
| Charge Injection | 3pC |
| Channel Capacitance (CS(off), CD(off)) | 6pF, 8pF |
| Current – Leakage (IS(off)) (Max) | 1nA |
| Crosstalk | -72dB @ 1MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-8 |
| Supplier Device Package | SOT-23-8 |
| Base Product Number | MAX4564 |
