Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Series | – |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Type | Standard (General Purpose) |
| Number of Elements | 1 |
| Output Type | CMOS |
| Voltage – Supply, Single/Dual (±) | 2.45V ~ 5.25V |
| Voltage – Input Offset (Max) | 5.5mV @ 5V |
| Current – Input Bias (Max) | 1.6µA @ 5V |
| Current – Output (Typ) | 19mA @ 5V |
| Current – Quiescent (Max) | 2.65mA |
| CMRR, PSRR (Typ) | – |
| Propagation Delay (Max) | 5.3ns |
| Hysteresis | – |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | 8-TSSOP, 8-MSOP (0.118″, 3.00mm Width) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-MSOP |
| Base Product Number | LTC6752 |
