| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Analog Devices Inc. |
| Series | Over-The-Top® |
| Packaging | Tape & Reel (TR), Cut Tape (CT), Digi-Reel® |
| Part Status | Active |
| Type | Standard (General Purpose) |
| Number of Elements | 1 |
| Output Type | Push-Pull, Rail-to-Rail |
| Voltage – Supply, Single/Dual (±) | 2.7V ~ 44V, ±1.35V ~ 22V |
| Voltage – Input Offset (Max) | 1.6mV @ 5V |
| Current – Input Bias (Max) | 0.05µA @ 5V |
| Current – Output (Typ) | 20mA @ 5V |
| Current – Quiescent (Max) | 60µA |
| CMRR, PSRR (Typ) | 110dB CMRR, 110dB PSRR |
| Propagation Delay (Max) | 5.5µs |
| Hysteresis | – |
| Operating Temperature | -40°C ~ 85°C |
| Package / Case | SOT-23-5 Thin, TSOT-23-5 |
| Mounting Type | Surface Mount |
| Supplier Device Package | TSOT-23-5 |
| Base Product Number | LT1716 |
