| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | American Zettler |
| Series | AZ9871 |
| Packaging | Tray |
| Part Status | Active |
| Coil Type | Non Latching |
| Coil Current | 47.2 mA |
| Coil Voltage | 12VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 30 A |
| Switching Voltage | 24VDC – Max |
| Must Operate Voltage | 6.9 VDC |
| Must Release Voltage | 1.5 VDC |
| Operate Time | 3 ms |
| Release Time | 1.5 ms |
| Features | Sealed – Epoxy |
| Mounting Type | Through Hole |
| Termination Style | PC Pin |
| Operating Temperature | -40°C ~ 105°C |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Coil Power | 567mW |
| Coil Resistance | 254 Ohms |
