Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | American Zettler |
| Series | AZ9322 |
| Packaging | Tray |
| Part Status | Active |
| Mounting Type | Through Hole |
| Coil Voltage | 12VDC |
| Contact Form | SPST-NC (1 Form B) |
| Contact Rating (Current) | 15 A |
| Switching Voltage | 277VAC – Max |
| Load – Max Switching | 1800VA |
| Coil Current | 30 mA |
| Coil Type | Non Latching |
| Features | – |
| Termination Style | PC Pin |
| Seal Rating | – |
| Coil Insulation | Class B |
| Must Operate Voltage | 9 VDC |
| Must Release Voltage | – |
| Operate Time | 10 ms |
| Release Time | 5 ms |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Approval Agency | – |
| Relay Type | General Purpose |
| Grade | – |
| Qualification | – |
| Coil Resistance | 400 Ohms |
| Base Product Number | AZ9322-1B |
