| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Altran Magnetics, LLC |
| Series | ALEV100 |
| Packaging | Box |
| Part Status | Active |
| Mounting Type | Chassis Mount |
| Coil Voltage | 48VDC |
| Contact Form | SPST-NO (DM) (1 Form X) |
| Contact Rating (Current) | 100 A |
| Switching Voltage | 1000VDC – Max |
| Features | Auxiliary Contacts |
| Termination Style | Stud, Wire Leads |
| Operating Temperature | -40°C ~ 85°C |
| Must Operate Voltage | 33 VDC |
| Must Release Voltage | 4.8 VDC |
| Contact Material | – |
| Operate Time | 25 ms |
| Release Time | 10 ms |
| Coil Current | 122 mA |
| Coil Power | 6W |
| Coil Resistance | 392Ohms |
