Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Advantech Corporation |
| Series | SMARC |
| Packaging | Box |
| Part Status | Active |
| Core Processor | Intel Core i3-N305 |
| Speed | 3.8GHz |
| Number of Cores | 8 |
| Power (Watts) | – |
| Cooling Type | Heat Spreader |
| Size / Dimension | 3.228″ x 1.969″ (81.99mm x 50.01mm) |
| Form Factor | SMARC2.1.1 |
| Expansion Site/Bus | CAN, GPIO, I2C, MIPI-DSI, PCIe, SPI, UART |
| RAM Capacity/Installed | 8GB/0GB |
| Storage Interface | I2C, PCIe, SATA 3.0, SPI |
| Video Outputs | DDI, DP++, eDP, HDMI, LCD, MIPI-DSI, Multi-Display |
| Ethernet | GbE (2) |
| USB | USB 2.0 (6), USB 3.2 Gen 2 (2) |
| Digital I/O Lines | 8 |
| Analog Input:Output | – |
| Watchdog Timer | Yes |
| Contents | – |
| Operating Temperature | 0°C ~ 60°C |
