Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Advantech Corporation |
| Series | 3.5″ MI/O-Compact |
| Packaging | Box |
| Part Status | Active |
| Core Processor | Intel Core i7-1185G7E |
| Speed | 4.4GHz |
| Number of Cores | 4 |
| Power (Watts) | 15W |
| Cooling Type | Fan |
| Size / Dimension | 5.750″ x 4.020″ (146.05mm x 102.10mm) |
| Form Factor | AT, ATX |
| Expansion Site/Bus | GPIO, I2C, SPI, LPC, PCIe, M.2, SMBus |
| RAM Capacity/Installed | 64GB/0GB |
| Storage Interface | SATA 3.0 (1) |
| Video Outputs | DP, HDMI, LCD, LVDS, Multi-Display |
| Ethernet | 10/100/1000 Mbps, RJ45 (2) |
| USB | USB 3.2 (5) |
| RS-232 (422, 485) | 4 |
| Digital I/O Lines | – |
| Analog Input:Output | – |
| Watchdog Timer | Yes |
| Contents | – |
| Operating Temperature | 0°C ~ 60°C |
| Base Product Number | MIO-5375 |
