Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Manufacturer | Advantech Corporation |
| Series | Mini-ITX Motherboard |
| Packaging | Box |
| Part Status | Active |
| Core Processor | Intel 8th/9th Gen Core i7/i5/i3/Pentium/Celeron LGA1151 |
| Speed | 1.8GHz ~ 3.7GHz |
| Number of Cores | 2/4/6/8 |
| Power (Watts) | 35W ~ 65W |
| Cooling Type | – |
| Size / Dimension | 6.690″ x 6.690″ (169.92mm x 169.92mm) |
| Form Factor | Mini-ITX |
| Expansion Site/Bus | LAN, M.2, PCIe |
| RAM Capacity/Installed | 64GB/0GB |
| Storage Interface | SATA 3.0 (2) |
| Video Outputs | DP, DVI, HDMI, LVDS |
| Ethernet | 10/100/1000 Mbps (3), RJ45 (2) |
| USB | USB 3.0 (4) |
| RS-232 (422, 485) | 6 |
| Digital I/O Lines | 16 |
| Analog Input:Output | – |
| Watchdog Timer | Yes |
| Contents | – |
| Operating Temperature | 0°C ~ 60°C |
| Base Product Number | AIMB-286 |
