Açıklama
| ÖZELLİK | AÇIKLAMA |
|---|---|
| Mfr | Adam Tech |
| Series | MDJ |
| Packaging | Tray |
| Part Status | Active |
| Connector Type | Jack, Female Sockets |
| Number of Positions | 8 |
| Shell Size – Insert | Mini DIN |
| Shell Size, MIL | – |
| Mounting Type | Through Hole, Right Angle |
| Mounting Feature | – |
| Termination | Solder |
| Fastening Type | Push-Pull |
| Orientation | Keyed |
| Primary Material | Metal |
| Shell Material | Copper Alloy |
| Shell Finish | Tin |
| Contact Finish – Mating | Gold |
| Color | Silver |
| Ingress Protection | – |
| Material Flammability Rating | UL94 V-0 |
| Features | Board Guide, Board Lock |
| Shielding | Shielded |
| Current Rating (Amps) | 1A, 2A |
| Voltage Rating | 100VAC, 12VDC |
| Cable Opening | – |
| Operating Temperature | -25°C ~ 70°C |
| Backshell Material, Plating | – |
| Contact Material | Phosphor Bronze |
| Contact Finish Thickness – Mating | – |
| Insert Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Applications | Audio, Video |
| Base Product Number | MDJ-008 |
